Illustration: replacing wiper blade
1. Turn off the wipers, switch the shift switch to
park, and then use the touch screen to move them
to the service position.
Before opening the maintenance mode, the wiper must be
in the off position.
2. Lift the wiper arm from the windshield.
3. Press the locking tab and slide the wiper blade out
from under the wiper arm.
4. Install a new wiper blade, adjust the new wiper
blade on the wiper arm and slide it towards the hook
end of the wiper arm until it locks.
5. Ensure that the wiper blade on the wiper arm is
close to the windshield.
6. If the problem still exists after using a new wiper
blade, clean the windshield and wiper blade with a soft
cloth or sponge dipped in warm water mixed with
non-detergent soap, and then wash the windshield and
wiper blade with clean water. If no water droplets are
formed, it indicates that the windshield has been
cleaned.
• only certified cleaning products suitable for
automotive glass and rubber can be used.
Improper use may cause damage or dirt and
glare on the windshield.
• only install the spare wiper blade which is
the same as the original wiper blade. If
improper wiper blades are used, the wiper
system may be damaged and the operation
of rain sensor may be affected.
• when replacing the wiper blade, please place
a rag or old clothes at the contact position
between the wiper blade and the front
windshield to prevent the front windshield
from being damaged due to the automatic
rebound of the wiper arm when the wiper
blade is removed.
Illustration: cleaning the wiper spray head
The position of the windshield washer is set at the factory
and does not need to be adjusted.
If the windshield washer is blocked, remove the
obstruction from the nozzle with a thin wire.
Do not operate the windshield washer when cleaning
the vehicle. Windshield washer fluid may irritate eyes
and skin. Please read and follow the instructions of the
wiper washer fluid manufacturer.
