7.1.4 Performance Characteristics (each component)
* error when used under reference conditions.
†
2510 HCL measurement less than 2% fsd (peak-peak) at minimum T
90
.
7.1.5 Performance Characteristics – EMC
Configuration of equipment:
Fitted with an unscreened power cable. Also included were two separate mA
output cables, each individually screened. Each signal pair was fitted with
ferrite bead (Servomex part No. 2824-0017). The screens and drain wires were
terminated at the glands.
Results:
Met the requirements of EN 61326, Table 4, Class B (Equipment for use in
domestic establishments) in respect of conducted and radiated emissions.
Met the requirements of EN 61326, Table A1 (Equipment for use in industrial
establishments) in respect of electrostatic discharges, fast transients/bursts,
surges, conducted RF disturbances, voltage dips and interrupts.
An additional error of 3% FS over the intrinsic error given in Table 7.2 may be
observed at some frequencies under the influence of radiated RF fields
specified for industrial environments.
Connection of additional or other signal/control cables and pressure
compensation could lead to a deterioration in performance at some RF
frequencies.
Table 7.2 – Performance Characteristics
Intrinsic Error* Less than ±1% fsd
Repeatability ±0.5% fsd
Output Fluctuation (Noise)
Less than 1% fsd (peak-peak) at minimum T
90
†
Linearity Error Typically less than ±1% fsd
Short Term Zero Drift: Less than ±1% fsd per week
Response Time (T
90
) User adjustable from 11s minimum (electronic
only, excludes sampling)
Obscuration Less than ±3% fsd zero error for 50% broadband
obscuration of cell windows
Influence Errors Dependant on application (see specification
details)
