Servomex 2500 Series User Manual

4.1
SECTION 4 INSTALLATION GAS CONNECTIONS
4.1 Purge Connections (EU1)
The next phase of the installation is to connect up any safety purge system required for
safe operation in a hazardous area.
4.1.1 General Purge Connections
Figure 4.1 Purge Connection Schematic
WARNING (EU1 VERSION)
Where appropriate, the user must refer to the detailed instructions provided
in the manual supplied with the Servomex 485/486 purge units or other Purge
Control System, and use them in conjunction with the following instructions.
