SECTION 7 INSTRUMENT SPECIFICATIONS
7.1 Generic 2500 Series Performance
7.1.1 Environmental Specifications
7.1.2 Dimensions
Length: Max 1618mm, (63.7") min 615mm (24.2")
Height: 241mm (9.5")(allow 500 mm (20")
to open end covers)
Width: 248mm (9.8")
Weight: from 25 kg (55 lb)
7.1.3 Power Supply
115/230V AC ±15%, 50/60Hz or 100/200V AC ±15%, 50/60Hz.
120 VA without optional electrically heated cell.
300 VA with optional electrically heated cell.
Power Supply
Voltage Effects: Less than ±1% fsd for ±15% change.
Power Supply
Frequency Effects: Less than ± 1% fsd for 47 to 53 Hz or 57 to 63 Hz.
Table 7.1 – General Environmental Specifications
Operating Temperature GEN, EU1, EU2, FM2, HTV 0-55°C (32-131°F)
Operating Humidity 0-95% RH, non-condensing
Storage Temperature -40°C(-104°F) to +70°C (158°F)
Storage Humidity 0-95% RH, non-condensing
Altitude Up to 3000 M
Installation Category II
Pollution Degree II
Over-voltage impulse to withstand up to 2500V
in accordance with IEC 60664-1
Rate of Ambient Temperature
Change
Less than ±25°C/h, (±45°F/h) Change
Warm-up Time Typically 2-10h, depending on application and
environment
