Servomex 2500 Series - Table 5.1 Diagnostic Displays

5.2
* (IF FITTED).
Table 5.1 – Diagnostic Displays
Display Description
CHOPPER TEMP °C Chopper box temperature
COMPENSATION °C Detector temperature
CELL TEMP °C Cell temperature (if enabled)
SAMPLE TEMP °C Sample Temperature *
[Measurement 1] ABS au Absolute absorbance units (M1)
[Measurement 2] ABS au Absolute absorbance units (M2) *
[Measurement 3] ABS au Absolute absorbance units (M3) *
SAMPLE PRESSURE (units) Sample pressure *
SOURCE VOLTS V Source voltage
MOTOR DRIVE %
SET POINT %
Motor drive power and set point
DETECTOR SIG M1 Detector signal level (M1) measurement
DETECTOR SIG M2 Detector signal level (M2) measurement *
DETECTOR SIG M3 Detector signal level (M3) measurement *
DETECTOR SIG R1 Detector signal (R1) reference
DETECTOR SIG R2 Detector signal (R2) reference *
DETECTOR SIG R3 Detector signal (R3) reference *
TEMP CORR M1 Temperature Correction (M1)
TEMP CORR M2 Temperature Correction (M2) *
TEMP CORR M3 Temperature Correction (M3) *
TEMP CORR R1 Temperature Correction (R1)
TEMP CORR R2 Temperature Correction (R2) *
TEMP CORR R3 Temperature Correction (R3) *
