54
Manual – MOVI-PLC® advanced DHE41B/DHF41B/DHR41B Controller
5
Configuration with the MOVITOOLS® MotionStudio PC software
Project Planning and Startup
• Setting the IP address of the PC interface:
– Select the relevant PC interface under [Start] / [Settings] / [Network Connections].
In the context menu, select the properties window of the PC interface.
– Activate the option "Use this IP address" in the property window of the "Internet
protocol (TCP/IP)" entry.
– Enter the net mask which is set in the MOVI-PLC
®
advanced DH.41B controller
(e. g. 255.255.255.0, if DIP switch S1 is in the upper position).
– Set the IP address depending on the net mask. The IP addresses of the MOVI-
PLC
®
advanced DH.41B controller (Ethernet 2) and the PC interface must be dif-
ferent except for the areas defined by the net mask. In the area defined by the net
mask, the IP addresses must be the same. The last byte of the IP address may
neither be 0 nor 255.
Example:
In the example, the last 8 bits of the IP address of the MOVI-PLC
®
advanced
DH..41B controller and the PC interface must be different.
Address settings
for engineering
access via a
network
Proceed as follows to establish engineering access to the MOVI-PLC
®
advanced
DH.41B controller via an existing network:
• In the section <Ethernet2...> of the NetConfig.cfg configuration file in the "System"
folder of the SD memory card, enter the following according to the specifications of
your network administration:
– IP address
–Net mask
– Gateway address
• Switch the DIP switch S1 to the lower position. This ensures that the new address
settings are adopted during the next boot process of the MOVI-PLC
®
advanced
DH.41B controller.
Net mask
decimal binary
255.255.255.0 11111111.11111111.11111111.00000000
00
I
