• Commands not indicated here are not guaranteed to operate.
Connecting a PC
NOTE
• If an underbar (_) appears in the parameter column, enter a space.
• If an asterisk (*) appears, enter a value in the range indicated in
brackets under CONTROL CONTENTS.
PC compatibility chart
RS-232C commands list
DDC is a registered trademark of Video Electronics Standards Association.
Power Management is a registered trademark of Sun Microsystems, Inc.
VGA and XGA are registered trademarks of International Business Machines Corp.
Resolution Horizontal Frequency Vertical Frequency Analogue (D-Sub) VESA Standard
VGA
640 g 480
31.5 kHz 60 Hz
✔✔
640 g 480
37.9 kHz 72 Hz
✔✔
640 g 480
37.5 kHz 75 Hz
✔✔
SVGA
800 g 600
35.1 kHz 56 Hz
✔✔
800 g 600
37.9 kHz 60 Hz
✔✔
800 g 600
48.1 kHz 72 Hz
✔✔
800 g 600
46.9 kHz 75 Hz
✔✔
XGA
1024 g 768
48.4 kHz 60 Hz
✔✔
1024 g 768
56.5 kHz 70 Hz
✔✔
1024 g 768
60.0 kHz 75 Hz
✔✔
WXGA
1360 g 768
47.7 kHz 60 Hz
✔✔
SXGA
1280 g 1024
64.0 kHz 60 Hz
✔✔
SXGA+
1400 g1050
65.3 kHz 60 Hz
✔✔
UXGA
1600 g1200
75.0 kHz 60 Hz
✔✔
1080p
1920 g1080
67.5 kHz 60 Hz
✔
—
NOTE
• This TV has only limited PC compatibility, correct operation can only be guaranteed if the video card conforms exactly to the VESA 60Hz
standard. Any variations from this standard will result in picture distortions.
CONTROL ITEM COMMAND PARAMETER CONTROL CONTENTS
POWER SETTING P O W R 0 _ _ _ POWER OFF (STANDBY)
INPUT SELECTION A I T G D _ _ _ _ INPUT SWITCHING (TOGGLE)
I T V D _ _ _ _ A-TV (CHANNEL FIXED)
I D T V _ _ _ _ D-TV (CHANNEL FIXED)
I A V D * _ _ _ INPUT1~8 (1-8)
CHANNEL D C C H * * _ _ TV DIRECT CHANNEL (1–99)
C H U P _ _ _ _ CHANNEL UP
C H D W _ _ _ _ CHANNEL DOWN
D T V D * * * _ D-TV DIRECT CHANNEL (1-999)
D T U P _ _ _ _ D-TV CHANNEL UP
D T D W _ _ _ _ D-TV CHANNEL DOWN
INPUT SELECTION B I N P 6 0 _ _ _ INPUT6 (AUTO)
I N P 6 1 _ _ _ INPUT6 (COMPONENT)
I N P 6 2 _ _ _ INPUT6 (S-VIDEO)
I N P 6 3 _ _ _ INPUT6 (VIDEO)
I N P 7 0 _ _ _ INPUT7 (AUTO)
I N P 7 1 _ _ _ INPUT7 (COMPONENT)
I N P 7 3 _ _ _ INPUT7 (VIDEO)
AV MODE SELECTION A V M D 0 _ _ _ TOGGLE
A V M D 1 _ _ _ STANDARD
A V M D 2 _ _ _ MOVIE
A V M D 3 _ _ _ GAME
A V M D 4 _ _ _ USER
A V M D 5 _ _ _ DYNAMIC (Fixed)
A V M D 6 _ _ _ DYNAMIC
AVMD7__ _PC
VOLUME V O L M * * _ _ VOLUME (0–60)
CONTROL ITEM COMMAND PARAMETER CONTROL CONTENTS
POSITION H P O S * * * _
H-POSITION (AV) (fnn ~ nn)
HPOS* * * _
H-POSITION (PC) (fnn ~ nn)
VPOS* * * _
V-POSITION (AV) (fnn ~ nn)
VPOS* * * _
V-POSITION (PC) (fnn ~ nn)
C L C K * * * _ CLOCK (0–180)
P H S E * * * _ PHASE (0–40)
WIDE MODE W I D E 0 _ _ _ TOGGLE (AV)
W I D E 1 _ _ _ NORMAL (AV)
W I D E 2 _ _ _ ZOOM 14:9 (AV)
W I D E 3 _ _ _ PANORAMA (AV)
W I D E 4 _ _ _ FULL (AV)
W I D E 5 _ _ _ CINEMA 16:9 (AV)
W I D E 6 _ _ _ CINEMA 14:9 (AV)
W I D E 7 _ _ _ NORMAL (PC)
W I D E 8 _ _ _ CINEMA (PC)
W I D E 9 _ _ _ FULL (PC)
W I D E 1 0 _ _ DOT BY DOT (AV/PC)
W I D E 1 1 _ _ UNDERSCAN (AV/PC)
WIDE12__
AUTO (During playback USB video only)
WIDE13__ ORIGINAL (During playback USB video only)
MUTE M U T E 0 _ _ _ TOGGLE
M U T E 1 _ _ _ MUTE ON
M U T E 2 _ _ _ MUTE OFF
SRS TS HD A C S U 0 _ _ _ SRS TS HD TOGGLE
A C S U 1 _ _ _ SRS TS HD ON
A C S U 2 _ _ _ SRS TS HD OFF
AUDIO CHANGE A C H A _ _ _ _ TOGGLE
SLEEP TIMER O F T M 0 _ _ _ OFF
O F T M 1 _ _ _ SLEEP TIMER 30 MIN
O F T M 2 _ _ _ SLEEP TIMER 1 HOUR
O F T M 3 _ _ _ SLEEP TIMER 1 HOUR 30 MIN
O F T M 4 _ _ _ SLEEP TIMER 2 HOUR
O F T M 5 _ _ _ SLEEP TIMER 2 HOUR 30 MIN
