8
Cup hook (commercially available)
Wall
Clamps
(supplied)
Affi x the TV to the wall or a
pillar using extra strong ties
and cup hooks.
Affi x the 2 clamps (supplied)
to the product using the
screws (supplied).
1
2
Tie (commercially available)
Screws for attaching clamps (supplied)
View from the top
Protection against overturning
There is a danger of the product overturning in the case of a disaster or sudden collision. Carry out the following
tip-resistant measurement for your safety.
Anchoring the TV to the wall or a pillar
Preparation
Insert commercially available screws in the
holes of the restraining brackets from the top
and tighten the screws to secure the TV to the
table.
Use commercially available screws of the proper
size to fi rmly secure the TV.
3
Fixing the TV to the table (For LC-60LX710H only)
Attach the two supplied restraining brackets to
the stand with four supplied screws.
Place the TV on the table.
1
2
CAUTION
As this product is heavy, use a table that is wide
enough to support the product and capable of
withstanding the product's weight. The table should
be set where it will not be overturned.
Be sure to use at least two people when moving the TV.
Stand
Restraining brackets
(supplied)
Screws
(Supplied)
Screws (Commercially
available)
Restraining brackets (supplied)
40LX710H_en.indd 840LX710H_en.indd 8 2010/04/15 16:11:082010/04/15 16:11:08
