Sharp LC-46LX650H - Protection against Overturning

14
Preparation
Screws
(commercially
available)
Protection against overturning
H
Applicable to LC-60LX650H only
Thereisadangeroftheproductoverturninginthecaseofadisasterorsuddencollision.Carryoutthefollowing
tip-resistantmeasurementforyoursafety.
PlacetheTVonthetable.
1
2
1
Use the 2 screws (supplied) to attach the 2
clamps(supplied)totherearoftheTV.
AttachtheTVtothewallusingextrastrong
ties(commerciallyavailable).
Pulltheattachedrestrainingbracketoutso
that it is at a 90 degrees angle.
Insertcommerciallyavailablescrewsinthe
holes of the restraining bracket and tighten the
screwstosecuretheTVtothetable.
• Usecommerciallyavailablescrewsoftheproper
sizetormlysecuretheTV.
2
3
Anchoring the TV to the wall or a pillar Fixing the TV to the table
CAUTION
• As this product is heavy, use a table that is wide enough to support the product and capable of withstanding the
product’s weight. The table should be set where it will not be overturned.
• BesuretouseatleasttwopeoplewhenmovingtheTV.
View from the top

 Cuphook(commerciallyavailable)

 Tie(commerciallyavailable)

 Screwsforattachingclamps(supplied)

 Clamps(supplied)
NOTE
•
When the attaching clamps is out of use, pull it in 90
o
so that hiding in the base.
wall
 


Restrainingbracket
(attached)
