Sharp MX-2600N Quick Start Guide

9
(12) Keyboard
This is a keyboard that is incorporated into the machine.
When not used, it can be stored under the operation
panel.
Use the keyboard to enter a password, file name, or
other text.
(13) Main power switch
This is used to power on the machine.
When using the fax or Internet fax functions, keep this
switch in the "on" position.
(14) Front cover
Open to replace a toner cartridge.
(15) Bypass tray
Special types of paper can be fed from the bypass
tray.
(16) Exit tray unit (right tray)*
When installed, output can be delivered to this tray.
(17) USB connector (type A)
This is used to connect a USB memory or other USB
device to the machine.
* Peripheral device. For more information, see "PERIPHERAL DEVICES" in "1. BEFORE USING THE
MACHINE" in the Operation Guide.
(13) (14) (15) (16) (17)(12)
mx3100_us_qck.book 9 ページ ２００８年３月１５日 土曜日 午後６時３０分

Sharp MX-2600N Specifications

Power

power requirements	230 ~240V AC, 50/60 Hz
power consumption	1.84 kW
warm-up time	Less than 60 sec.

System Memory

copier memory	Standard 1, 024MB, max. 2, 048MB
printer memory	Standard 512MB, max. 1, 536MB
HDD	80GB

Paper Handling

standard paper capacity	1, 100 sheets
maximum paper capacity	5, 600 sheets
paper weight (tray)	60 g/m² to 209 g/m²

Weight and Dimensions

dimensions	620 x 695 x 950 mm
weight	Approx. 112 kg
