Sharp MX-2600N Quick Start Guide

19
Loading paper in a tray
To change the paper in a tray, load the desired paper in the tray and then change the tray settings in the machine
to specify the loaded paper. The procedure for changing the tray paper size is explained below. As an example,
the paper in tray 1 is changed from 8-1/2" x 14" (B4) size plain paper to 8-1/2" x 11" (A4) size recycled paper.
Tray 3 and tray 4 can automatically detect the size of the loaded paper. In this case, the tray settings change
automatically.
Gently pull out the paper tray.
If paper remains in the tray, remove it.
Insert the paper with the print side face
up.
Fan the paper well before inserting it.
Otherwise, multiple sheets may feed at
once and cause a misfeed.
Insert the paper and then gently push the
tray into the machine.
Move the two guides on the tray. For
example, move the guides from
8-1/2" x 14" (B4) to 8-1/2" x 11" (A4).
Indicator line
The indicator line indicates the maximum
height of the paper that can be loaded in
the tray. When loading paper, make sure
that the stack is not higher than the
indicator line.
Do not load as shown below.
01-1_Quick(General).fm 19 ページ ２００８年５月２８日 水曜日 午後７時１３分

Sharp MX-2600N Specifications

Power

power requirements	230 ~240V AC, 50/60 Hz
power consumption	1.84 kW
warm-up time	Less than 60 sec.

System Memory

copier memory	Standard 1, 024MB, max. 2, 048MB
printer memory	Standard 512MB, max. 1, 536MB
HDD	80GB

Paper Handling

standard paper capacity	1, 100 sheets
maximum paper capacity	5, 600 sheets
paper weight (tray)	60 g/m² to 209 g/m²

Weight and Dimensions

dimensions	620 x 695 x 950 mm
weight	Approx. 112 kg
