Sharp MX-2600N Quick Start Guide

21
Loading paper in other trays
Bypass tray
Place paper that is 7-1/4" x 10-1/2" (A5) or smaller
in the horizontal orientation.
Only the address side of envelopes can be printed on.
Place envelopes with the address side face down.
Special types of paper that cannot be loaded in other trays can be loaded in the bypass tray.
For detailed information on the bypass tray, see "LOADING PAPER IN THE BYPASS TRAY" in "1. BEFORE
USING THE MACHINE" in the Operation Guide.
When loading 12" x 18", 11" x 17", 8-1/2" x 14", or
8-1/2" x 13"R size paper, pull out the tray extension.
The maximum number of sheets that can be loaded
in the bypass tray is approximately 100 for plain
paper and approximately 20 for envelopes.
The side to be
copied on must
be face down!
Example: Loading an envelope
01-1_Quick(General).fm 21 ページ ２００８年５月２８日 水曜日 午後７時１６分

Sharp MX-2600N Specifications

Power

power requirements	230 ~240V AC, 50/60 Hz
power consumption	1.84 kW
warm-up time	Less than 60 sec.

System Memory

copier memory	Standard 1, 024MB, max. 2, 048MB
printer memory	Standard 512MB, max. 1, 536MB
HDD	80GB

Paper Handling

standard paper capacity	1, 100 sheets
maximum paper capacity	5, 600 sheets
paper weight (tray)	60 g/m² to 209 g/m²

Weight and Dimensions

dimensions	620 x 695 x 950 mm
weight	Approx. 112 kg
