The items in the above step must be entered. For details on items entered, see "7. SYSTEM SETTINGS" in the
Operation Guide.
When sending the same document or image to multiple destinations, it is convenient to store a destination group.
For details on storing groups, see "7. SYSTEM SETTINGS" in the Operation Guide.
Select settings in the touch panel. (Continued)
(4) Select [Fax] from the "Address Type" select
box.
(5) Touch the "Address Name" text box.
A text entry screen appears. Enter the name of the
destination.
(6) Touch the "Initial" text box.
A text entry screen appears. Enter search characters
for the destination.
(7) Touch the scroll bar to move the screen.
(8) Touch the "Fax Number" text box.
A text entry screen appears. Enter the fax number that
you wish to store.
(9) Touch the [OK] key.
Cancel
System Settings
Address Control
System Settings
Address Control
Address Type:
Address Name
(Required):
Search Number:
Initial (Optional):
Key Name:
Custom Index:
Register this Address to be added to the [Frequent Use] index.
Register this Address to be added to the [Frequent Use] index.
Fax
1
K
KKK KKK
User 1
(1-999)
OK
Cancel
OK
Fax Number (Required):
Transmission Mode:
33.6 kbps
0123456789
None
Transmission Speed:
Transmission Mode:
(7)
(4)
(8)
(9)
(6)
(5)
04-1_Quick(Fax).fm 67 ページ ２００８年４月１８日 金曜日 午前９時２８分

Sharp MX-2600N Specifications

Power

power requirements	230 ~240V AC, 50/60 Hz
power consumption	1.84 kW
warm-up time	Less than 60 sec.

System Memory

copier memory	Standard 1, 024MB, max. 2, 048MB
printer memory	Standard 512MB, max. 1, 536MB
HDD	80GB

Paper Handling

standard paper capacity	1, 100 sheets
maximum paper capacity	5, 600 sheets
paper weight (tray)	60 g/m² to 209 g/m²

Weight and Dimensions

dimensions	620 x 695 x 950 mm
weight	Approx. 112 kg
