24
MU 6040 C/D and MU 6042 D
The following numbers when no loudspeaker is connected. If loudspeakers are used, then use the tables for DC 6120 P
or DC 6190 P.
1 m Spacing Between Microphone Units
Cable Length Maximum Number of Microphone Units
CCU to the first unit Total One Chain
100 m 151 m 52
150 m 191 m 42
2 m Spacing Between Microphone Units
Cable Length Maximum Number of Microphone Units
CCU to the first unit Total One Chain
10 m 168 m 80
30 m 178 m 75
50 m 188 m 70
100 m 200 m 51
150 m 200 m 26
IS 6132 P Interpreter Units
The following numbers when no loudspeaker is connected. If loudspeakers are used, then use the tables for DC 6120 P
or DC 6190 P.
Note: The number of units available depends on how many interpreter units there are per booth (per language), as
there only one unit can be switched ON per language (channel).
2 Meters between Units
Length From CCU to First
Conference Unit
Maximum Number of Units
All On 1/2 On 1/3 On
10 m 54 x x
30 m 49 57 60
50 m 44 51 x
100 m 35 40 x
150 m 25 30 x
