13.3 Supply
Table 63: Supply
Supply voltage V
S
18VDC … 30VDC, reverse polarity protected
Current consumption (with‐
out load)
■
Without heating: <250mA at 24VDC
■
With heating: <1,000mA at 24VDC
Residual ripple <5V
SS
within the permissible supply voltage U
V
13.4 Inputs
Table 64: Inputs
Inputs Multifunctional input MF1, switching function adjustable
Switching type: Sink for PNP output (open input corresponds to the
LOW input signal)
■
HIGH >12V
■
LOW <3V
Circuit protection None, no reverse-polarity protection.
13.5 Outputs
Table 65: Outputs
Outputs Multifunctional outputs MF1 and MF2, type B (push/pull), adjusta‐
ble switching function
■
HIGH > U
V
– 3V
■
LOW <2V
Circuit protection
■
Short-circuit protected
■
Overload-proof
Maximum output current Max. 100mA
Output load
■
Capacitive: 100nF
■
Inductive: 20mH
13.6 Interfaces
Table 66: Interfaces
Process data interface CANopen
Ethernet Configuration/Service interface (SOPAS ET)
13.7 Ambient data
Table 67: Ambient data
Protection class
Suitable for operation in PELV (Protective Extra Low Voltage) sys‐
tems with safe separation.
Electromagnetic compati‐
bility
EN61000-6-2, EN61000-6-4, Class A
Ambient operating temper‐
ature range
–20...+55°C
2)
–40...+55°C (with integrated heating)
3)
-20...+75°C (with cooler housing TPCC)
