SICK DL100 Pro CANopen - More? Menu

Table 14: CANopen menu
Parameter Description
NodeID Enter the node ID for the CANopen device.
For more information on data formatssee "Address assignment (node ID)",
page 88.
Factory setting
•
6
Baud Enter the baud rate for the device.
Options
•
125k
•
250k
•
500k
•
800k
•
1000k
Factory setting
•
500k
ResDst Select the resolution in mm for the distance output value via the digital
data interface. The output value corresponds to the measured value [mm]
divided by the selected resolution. The parameter does not have any influ‐
ence on the measured value shown on the display.
Options
•
0.1[mm]
•
0.125[mm]
•
1.0[mm]
•
10.0[mm]
•
100.0[mm]
•
freRes
Factory setting
•
0.1[mm]
NOTE
freRes = free resolution see "Object 4000h – Distance Resolution",
page 77
ResSpd Select the resolution in mm/s for the speed output value via the digital data
interface. The output value corresponds to the measured value [mm/s] div‐
ided by the selected resolution. The parameter does not have any influence
on the measured value shown on the display.
Options
•
0.1[mm/s]
•
1.0[mm/s]
•
10.0[mm/s]
•
100.0[mm/s]
•
freRes
Factory setting
•
1.0[mm/s]
NOTE
freRes = free resolution see "Object 4001h – Velocity Resolution", page 77
7.1.6 More? menu
In the more? menu, you can activate or deactivate the advanced menu view.
OPERATION 7
