8 Ethernet interface
An Ethernet interface is available on the device.
It can be used for communication via SICK configuration software SOPAS ET see
"SOPAS ET configuration software", page 49.
Each device has its own MAC address. The MAC address can be found on the type label
see "Type label", page 14.
NOTE
You can download the SOPASET configuration program online at www.sick.com/
SOPAS_ET.
8.1 Features
The Ethernet interface has the following features:
•
Transmission rate 10 or 100MBit, half or full duplex
•
Auto-negotiation (automatic adjustment of transfer rate and duplex procedures)
•
Auto-crossover (automatic adjustment in the case of Ethernet cables)
•
DHCP (dynamic IP address assignment via DHCP server) or static IP address
assignment
8.2 IP network configuration
During delivery or after a reset to factory settings, the following IP network configuration
is set on the device:
•
Dynamic IP address assignment via DHCP switched off
•
Static IP address assignment switched on
•
IP address: 192.168.100.236
•
IP network mask: 255.255.255.0
•
Default gateway: 0.0.0.0
You can change the IP network configuration via the SOPAS ET configuration software.
NOTE
If address assignment using the DHCP server is parameterized and it fails, the last
selected static IP address is used for the device. The delivery configuration is used
if this static IP address is invalid (IP address 0.0.0.0). This process may take up to
approx. 1minute. If the IP address is 0.0.0.0, the device cannot be found via SOPAS ET.
It may be necessary to reset to factory settings and restart the device.
