13 Technical data
NOTE
The relevant online product page for your product, including technical data, dimensional
drawing, and connection diagrams, can be downloaded, saved, and printed from the
Internet.
The call is made via the SICK Product ID: pid.sick.com/{P/N}/{S/N}
{P/N} corresponds to the part number of the product, see type label.
{S/N} corresponds to the serial number of the product, see type label (if indicated).
Please note: This documentation may contain further technical data.
13.1 Optics
Table 61: Laser/optics
Light sender Laser diode, red light
Laser class 2 in accordance with EN 60825-1/CDRH
CW modulation ±0.85Po sinusoidally modulated
Maximum peak output ≤1.9mW
Pulse duration 6.8ns
Average performance P
0
<1mW
Shaft Length 655nm
Frequency ≥90MHz
Light spot size Typically 5mm + (2mm x distance [m])
Average service life Typically 100,000h at +25°C ambient temperature
13.2 Performance data
Table 62: Performance data
Measuring ranges
•
DL100–21XXXXXX: 0.15m … 100m
•
DL100–22XXXXXX: 0.15m … 200m
•
DL100–23XXXXXX: 0.15m … 300m
Measuring object On Diamond Grade reflective tape DG983
Measurement accuracy
•
DL100–21XXXXXX: ±2.0mm
•
DL100–22XXXXXX: ±2.5mm
•
DL100–23XXXXXX: ±3.0mm
Repeatability
2)
•
DL100–21XXXXXX: ±0.50mm
•
DL100–22XXXXXX: ±1.00mm
•
DL100–23XXXXXX: ±2.00mm
Measurement cycle time 1ms
Response time/Measured
value age
2ms
Initialization time
■
Typically 1.5s
■
After reflector loss: <40ms
1)
The measurement accuracy can be up to ±4mm in the 150mm...180mm measuring range.
2)
Statistical error 1 σ, environmental conditions constant, minimum warm-up time 10min.
