SICK DL100 Pro CANopen - Structural Design

Warehouse ambient tem‐
perature range
-40…+75°C
Relative humidity Max 95% (non-condensing)
Enclosure rating IP65
Effect of air pressure 0.3ppm/hPa
Effect of temperature 1ppm/K
Temperature drift Typically 0.1mm/K
Maximum traversing speed 15m/s
Maximum acceleration 15m/s²
Mechanical strength EN 60068-2-27 (Ea): Continuous shock: 25g/6ms, half sine, 6
axes, 500 shocks per axis
EN 60068-2-27 (Ea): Shock: 30g/6ms, half sine, 6 axes, 3
shocks per axis
EN 60068-2-64 (Fh): Broadband noise vibrations: 10g rms, 10…
500Hz, 6 axes, 2h per axis
1)
The device may cause interference if used in a residential environment.
2)
A warm-up phase until activation of the laser diode is required for temperatures under –10°C; typical
duration at –20°C: 20min at 24V.
3)
For operation below –20°C, a supply voltage of at least 24V is required. A warm-up phase up until
activation of the laser diode is required for temperatures under –10°C: typical duration at –40°C:
35min at 24V.
4)
Maximum 95% humidity, non condensing
13.8 Structural design
Table 68: Structural design
Dimensions see "Dimensional drawing", page 102
Weight
■
Device: approx. 800g
■
Alignment bracket (optional): approx. 800g
Materials
■
Housing: Cast aluminum GD-AlSi12Cu1 (3.2982.05)
■
Viewing window: PMMA
Connections
•
M12, SpeedCon™-compatible
Display
■
6-digit with a 5 x 7 dot matrix
TECHNICAL DATA 13
8015418/19HA/2022-12-15 | SICK O P E R A T I N G I N S T R U C T I O N S | DL100 Pro CANopen
101
Subject to change without notice
