Requirement for display:
•
more? menu: Yes option
•
Menu MFx On: Enable option
Table 22: MF2 menu
Parameter Description
ActSta Select active MF2 level.
Options
•
ActLow: LOW level output with active output (safety criterion fulfilled)
•
ActHi: HIGH level output with active output (safety criterion fulfilled)
Factory setting
•
ActLow
Functn Select MF2 function.
Options
•
Dist: MF2 is used as a distance switch output.
•
Speed: MF2 is used as a speed switch output.
•
Srvice: MF2 is used as a service output.
Factory setting
•
Srvice
Count Counts the switching events of the MF2. You can reset the counter by
switching the device off and on again.
MF2 – Dist submenu
This submenu corresponds to the Dist submenu in the MF1 menu see "MF1 – Dist
submenu", page 39.
MF2 – Speed submenu
This submenu corresponds to the Speed submenu in the MF1 menu see "MF1 – Speed
submenu", page 40.
MF2 – Srvice submenu
This submenu corresponds to the Srvice submenu in the MF1 menu see "MF1 – Srvice
submenu", page 41.
7.1.15 Offset menu
You can set an offset in this menu.
Requirement for display:
•
more? menu: Yes option
Table 23: Offset menu
Parameter Description
Offset Specify the offset. The offset is added to the internally determined distance
value. The offset is applied to all outputs and to what is shown on the
distance display.
Triggering a preset overwrites the offset. The following applies: Offset =
Preset - measured distance value.
Options
•
–600,000 … +300,000[mm]
Factory setting
•
0[mm]
