Data Field: User data (0-8bytes) Data field 0-64
CRC Seq.: CRC Sequence CRC Seq. 15
CRC Del.: CRC Delimiter CRC Del. 1
ACK Slot: Acknowledge Slot ACK Slot 1
ACK Del.: Acknowledge Delimiter ACK Del. 1
EOF: End of Frame EOF 7
10.3.6 Structure of 11-bit CAN ID
NOTE
The device supports only 11-bit CAN IDs.
The 11-bit CAN ID is composed of the function code (see specification CiA 301) and the
node ID.
Table 29: Structure of the 11-bit CAN ID
MSB LSB
10 9 8 7 6 5 4 3 2 1 0
11-bit CAN ID
Function code Node ID
MSB LSB
Example for Transmit SDO with node ID 6
The Transmit SDO object has function code 1011b. Combining this with node ID 6
(0110b) results in a CAN ID with the value 586h.
Table 30: Example of Transmit SDO object
MSB LSB
10 9 8 7 6 5 4 3 2 1 0
11-bit CAN ID
Function code Node ID
1 0 1 1 0 0 0 0 1 1 0
5h 8h 6h
MSB LSB
10.3.7 Identifier priority
The lower the CAN ID, the higher the priority of the telegram. The following figure shows
the distribution and priority of the CAN identifiers.
