SICK DT80 IO-Link User Manual

11.3 Mechanics/Electronics
Supply voltage (U
V
) 12V...30VDC
1)
,
2)
Residual ripple ≤5V
pp
3)
Power consumption ≤2W
4)
Power-up time 1,100ms
5)
Warm-up time ≤1min
Housingmaterial Metal (zinc die cast)
Viewing window material Plastic (PMMA)
Connection type Male connector, M12, 5-pin + female connector, M12, 4-pin
Cable with male connector, M12, 5-pin, 300mm
Display 4 x LED, full color LC display
Enclosure rating IP65, IP67 (IEC 60529:1989+AMD1:1999+AMD2:2013)
Protection class III (IEC 61140:2016-11)
Weight 280g
Dimensions (L x W x H) 33mm x 65mm x 57.04mm
1)
Limit values, reverse-polarity protected. Short circuit-protected mains operation: max. 5A at 30VDC.
2)
When using the analog output: U
V
>13V
2)
When using IO-Link: U
V
>18V. When using the analog output: U
V
>13V
3)
Must not fall short of or exceed U
V
tolerances.
4)
At ambient temperature ≥0°C
5)
Depends on the measurement cycle time
11.4 Ambient data
Vibration resistance (IEC 60068-2-6:2007) Sinusoidal resonance measurement:
10Hz ... 1,000Hz
(IEC 60068-2-64:2008) Noise test: 20Hz ... 500Hz, 10g RMS,
2h/axis
Shock resistance (IEC 60068-2-27:2008) 30g, 11ms, 6axes, ±3 single shocks/
axis
(IEC 60068-2-27:2008) 10g, 6ms, 6axes, ±500shocks/axis
(IEC 60068-2-27:2008) 70g, 6ms, 1axis, ±100,000shocks/
axis
Typ. ambient light immun‐
ity
30000lx
Ambient temperature,
operation
-10°C … +50°C
Ambient temperature, stor‐
age
–40°C ... +75°C
TECHNICAL DATA 11
8028220.1N23/2024-05-24 | SICK O P E R A T I N G I N S T R U C T I O N S | DT80 IO-Link
41
Subject to change without notice
