SICK DT80 IO-Link User Manual

11 Technical data
NOTE
The relevant online product page for your product, including technical data, dimensional
drawing, and connection diagrams, can be downloaded, saved, and printed from the
Internet.
The product page can be accessed via the SICK ProductID: pid.sick.com/{P/N}/{S/N}
{P/N} corresponds to the part number of the product, see type label.
{S/N} corresponds to the serial number of the product, see type label (if indicated).
Please note: This documentation may contain further technical data.
11.1 Performance
Measuring range 50mm...14,000mm (for 6% remission factor)
1)
50mm...40,000mm (for 90% remission factor)
50mm…80,000mm (for 90% remission factor)
2)
Resolution 0.1mm
Repeatability
3)
,
4)
,
5)
≥ 0.2mm
Measurement accuracy ± 2mm
4)
,
5)
Light sender Laser, red
6)
Visible red light
Laser class 2 (IEC60825-1:2014, EN60825-1:2014+A11:2021)
Typ. light spot size (dis‐
tance)
5.5mm x 7.5mm (at 1m)
6.5mm x 7mm (at 5m)
7.5mm x 6.5mm (at 10m)
12.5mm x 8mm (at 20m)
21.5mm x 11mm (at 40m)
Average laser lifespan
(MTTF at 25°C ambient
temperature)
100,000h
1)
At the maximum permissible ambient temperature, the maximum measuring range may be reduced by up
to 40%.
2)
At good ambient conditions, at measurement cycle time ≤3,000ms
3)
See diagrams for repeatability
4)
Equivalent to 1 σ
5)
6% ... 90% remission factor
6)
Typical temperature drift: 0.05mm/K
7)
Wavelength: 655nm; max. average power: <1mW; pulse length: >400ps;
Table 14: Response time as a function of output time
Output time

1
33ms 50ms 100ms 200ms ≤3000ms
Response
time 
2
min. 33ms;
<68ms
min. 50ms;
<102ms
min. 100ms;
<202ms
min. 200ms;
<402ms
min. 300ms;
<6000ms
1
Continuously changing data output
2
Depends on the object and filter settings
TECHNICAL DATA 11
8028220.1N23/2024-05-24 | SICK O P E R A T I N G I N S T R U C T I O N S | DT80 IO-Link
37
Subject to change without notice
