SICK DT80 IO-Link User Manual

Repeatability
0
Typ. repeatability in mm (inch) 1
0
Distance in m (ft) 2
5
(16.4)
10
(32.8)
15
(49.2)
20
(65.6)
25
(82.0)
30
(98.4)
35
(114.8)
40
(131.2)
0.50
(0.02)
1.00
(0.04)
1.50
(0.06)
2.00
(0.08)
2.50
(0.10)
3.00
(0.12)
3.50
(0.14)
4.00
(0.16)
a: 33 ms
b: 50 ms
c: 100 ms
d: 200 ms
d
c
b
a
Figure 10: Repeatability at 90% remission, 10,000lux
1
Typical repeatability in mm (inches)
2
Distance in meters (feet)
11 TECHNICAL DATA
38
O P E R A T I N G I N S T R U C T I O N S | DT80 IO-Link 8028220.1N23/2024-05-24 | SICK
Subject to change without notice
