SICK DT80 IO-Link

0
Typ. repeatability in mm (inch) 1
0
Distance in m (ft) 2
5
(16.4)
10
(32.8)
15
(49.2)
20
(65.6)
25
(82.0)
30
(98.4)
35
(114.8)
40
(131.2)
0.50
(0.02)
1.00
(0.04)
1.50
(0.06)
2.00
(0.08)
2.50
(0.10)
3.00
(0.12)
3.50
(0.14)
4.00
(0.16)
a: 33 ms
b: 50 ms
c: 100 ms
d: 200 ms
d
c
b
a
Figure 11: Repeatability at 90% remission, 30,000lux
1
Typical repeatability in mm (inches)
2
Distance in meters (feet)
0
Typ. repeatability in mm (inch) 1
0
Distance in m (ft) 2
2
(6.6)
4
(13.1)
6
(19.7)
8
(26.2)
10
(32.8)
12
(39.4)
14
(45.9)
16
(52.5)
0.50
(0.02)
1.00
(0.04)
1.50
(0.06)
2.00
(0.08)
2.50
(0.10)
3.00
(0.12)
3.50
(0.14)
4.00
(0.16)
a: 33 ms
b: 50 ms
c: 100 ms
d: 200 ms
d
c
b
a
Figure 12: Repeatability at 6% remission, 10,000lux
1
Typical repeatability in mm (inches)
2
Distance in meters (feet)
