SICK Flexi Compact User Manual

Further topics
•
"St
atus indicators", page 119
•
"Input elements", page 45
•
"Diagnostics using Safety Designer", page 124
11.3 Diagnostics using Safety Designer
Prerequisites
•
T
he safety controller must be connected to Safety Designer.
Diagnostics area
The main navigation menu has a Diagnostics area. This area contains the following
functions:
•
Error history main module : Displays all messages, information, warnings, and error
messages of the safety controller.
11.3.1 Error history
Error history
T
able 136: Error history information
Keyword Description
Type Error type (e.g., information, warning, recoverable error, serious error)
Occurrence Operating time between when the main module was last switched
on and when t
he error occurred (power-on cycles of the main mod‐
ule/days:hours:minutes:seconds)
Local time of
occurrence
Time when the error occurred (system time of the computer).
This value is not displayed for historical errors.
Site Module position and type code of the module that detected the error
Error code Hexadecimal error code
Support info Internal information about the error
Message Description of the fault that occurred
Acknowledged The error has been marked as viewed
Reason Detailed information on the cause of the error
Solution Suggested solution for eliminating the error
Complementary information
Clic
king an entry in the list selects that entry and displays the details of the selected
message.
The diagnostic messages are also included in the report. You can use the report to save
or print out the diagnostic messages.
Further topics
•
"R
eport main navigation menu", page 112
11 T
ROUBLESHOOTING
124
O P E R A T I N G I N S T R U C T I O N S | Flexi Compact 8024589/2020-11-10 | SICK
Subject to change without notice
