Product description
Probe version
Fig. 8 F1F-P
1 Pressure compensation element 6 Retraction nozzle
2 Electronics unit 7 Duct probe
3 T-connector 8 Transducer
4 Pressure compensation element 9 Sensor contour
5 Self-cutting ring
1
7
86
4
532
9
