8OPERATION
2. Set lower limit value (0 V).
• Set the value in the QAMENU-QALOW menu to level in mm (e.g., 10 mm).
3. Invert the signal.
The analog signal can be inverted in the QAPOL menu.
Set the parameter in the QxMENU-QAPOL menu to QA-INV.
• QA-NRM = Analog output signal as congured
• QA-INV = Analog output signal is inverted; QAHIGH 0V and QALOW 10 V
4. Select electrical signal.
Set the parameter in the QxMENU-QATYP menu to 0 V ... +10 V
8.4 Advanced functions
8.4.1 Expert mode
Expert mode must rst be set to activate special functions.
Log in to expert mode
1. Access the PASSW menu using the arrow pushbuttons.
2. Enter password 000537 (LFP on the mobile keypad: L=5 / F=3 / P=7).
Expert mode may be locked again if the password is entered incorrectly or if the power
supply is disconnected.
8.4.2 Filtering measured values
Activate ltering
Smoothing of the measured value; e.g., in the case of ripples on level surfaces. For fast
level changes, the average of the measured values over X seconds is indicated.
b Set the parameter in the Filter menu.
The possible values are O, 400 ms, 600 ms, 1,000 ms, 1,400 ms, 2 s, 5 s, 10 s.
Maximum change of level (plausibility check)
For applications that cause the level to jump on the LFP due to signicant interference.
Enter the max. level dynamic value in the application, or the maximum permissible rate
of change of the ll level.
1. Log in to expert mode, see “8.4.1 Expert mode”.
2. Reduce the parameter in the EXPRT-CONFIG-MaxCol menu.
AnySpd (50 cm/s) (default), 10 cm/s, 5 cm/s, 2 cm/s
Note:
• For MeasMd = HiSpd, any max. change rate is possible
• For MeasMd = HiAcc, max. is 10 cm/s
