8OPERATION
Conguration
1. Log in to expert mode, see “8.4.1 Expert mode”.
2. Dene the parameter in the EXPRT-Cong-MaskZn menu.
Note:
This setting can only be used in Pulse mode.
8.4.5 Selecting evaluation process
You can switch between Pulse mode and Foam mode for the evaluation process.
Dierent evaluation algorithms are used depending on the mode selected.
Conguration
1. Log in to expert mode, see “8.4.1 Expert mode”.
2. Select either Pulse or Foam in the EXPRT-Cong-Mode menu.
Where the following applies:
• Mode = Pulse: The sensor measures either with or without AutCal.
• Mode = Foam: The sensor measures only with valid CalEmp+CalMed. If there are
no valid calibrations, the message CalPIs is shown and the sensor goes into the
safe state.
Note:
If AutCal is accessed while the sensor is in Foam mode, AutCal is denied with the error
message !Denid.
8.4.6 Testing the conguration
Testing outputs
Switching / analog outputs can be simulated. This allows for the wiring and signal
values on the connected systems, such as the PLC control, relay, and lamps, to be
checked.
Conguration
Activate the Qx switching output
b Set the parameter in the QxMENU-SimQx menu to QxOn.
Further options:
• QxO = switching output o
• QxNorm = switching output in measuring operation
• QxOn = switching output is active
Note:
The simulation is automatically deactivated if the supply voltage is interrupted.
