15 DIMENSIONAL DRAWINGS
15 Dimensional drawings
LFP Inox standard version
123 (4.84)
22
(0.87)
L
IA
M
IAE
36 (1.42)
54 (2.13)
38 (1.50)
M12x1
20 (0.79)
145 (5.71)
22 (0.87)
15 (0.59)
L
G 3/4 A
3/4" NPT
IAE
IA
M
32
(1.26)
G 3/4 A
3/4" NPT
7 (0,28)
77 (3.03)
Mono-probe with coaxial tube
M Measuring range
L Probe length
IA Inactive area at process connection 25 mm
IAE Inactive area at probe end 10 mm
LFP Inox cable version
L
22 (0.87)
123 (4.84)
IA
IAE
M
36 (1.42)
G 3/4 A
3/4" NPT
7 (0.28)
77 (3.03)
43 (1.69)
115 (4.53)
approx . 10000 (393.70)
54 (2.13)
M12
M Measuring range
L Probe length
IA Inactive area at process connection 25 mm
IAE Inactive area at probe end 10 mm
