14 TECHNICAL DATA
14 Technical data
14.1 Features
Medium Liquids
Detection type Limit, continuous
Probe length 200 mm ... 4,000 mm
Adjustable measuring range 95 mm ... 6,005 mm
Process pressure –1 bar ... +16 bar
Process temperature –20 °C ... +150 °C
EHEDG certicate

GOST certicate

RoHS certicate

IO-Link

3A approval

UL certicate

14.2 Performance
Accuracy
1)
± 5 mm
Repeatability
1)
≤ 2 mm
Resolution < 2 mm
Response time
3)
< 400 ms
Dielectric constant ≥ 5 for mono-rod probe
≥ 1.8 with coaxial tube
Conductivity No limitation
Maximum change of level
4)
500 mm/s
Inactive area at end of probe
1)
10 mm
1)
With water under reference conditions, see “14.7 Measurement accuracy”.
2)
With parameterized container with water under reference conditions, otherwise 40 mm.
3)
Depends on measuring mode (high-speed < 400 ms, high accuracy < 2,800 ms)
4)
Depends on configuration (MaxCol - maximum change of level)
