SICK UM18-2 Pro User Manual

8014865/ZUJ3/2018-11-29 • © SICK AG • Subject to change without notice 35
IO-Link interface
8.3.3 SICK-specicUM18-21712A21_
Index
decimal
(hex)
Description Format Access Value range Example Remarks
64 (0x40) Switching point 1 UINT16 R/W 436 ... 5065
(30 ... 348 mm)
800 corresponds
to 55 mm
Specify values
as a multiple
of the internal
measurement value
resolution (0.069 mm).
65 (0x41) Switchback point 1 UINT16 R/W 451 ... 5080
(31 ... 349 mm)
71 (0x47) Switching point 2 UINT16 R/W 466 ... 65512
1)
(32 ... 350 mm)
72 (0x48) Switchback point 2 UINT16 R/W 451 ... 65512
1)
(31 ... 349 mm)
73 (0x49) Foreground
suppression
UINT8 R/W 0 ... 3246
(0 ... 223 mm)
66 (0x42) Switching output
function
UINT8 R/W • 00: normally closed
• 02: normally open
–
67 (0x43) Filter UINT8 R/W • 00: F00
2)
• 01: F01
• 02: F02
→ See also Page 29,
Chapter 7.5.
68 (0x44) Filter strength UINT8 R/W • 00: P00
• 01: P01
• 02: P02
• 03: P03
• 04: P04
• 05: P05
• 06: P06
• 07: P07
• 08: P08
• 09: P09
For the selected
measured value lter,
you can select a lter
strength between 0
(weak ltering eect)
and 9 (strong ltering
eect).
74 (0x4A) Teach via pin 5 in
SIO mode
UINT8 R/W • 00: deactivated
• 16: activated
–
Teach
Index
decimal
(hex)
Description Access Access Value range Example Remarks
02 (0x02) TEACH UINT W • 161: Method A
• 162: Method B
• 164: Two-way
reection barrier
• 168: Reset to
factory setting
A teach overwrites
a function that has
already been set
with a newly selected
function.
If a teach is not
successful, the old
value is retained.
→ See Page 23,
Chapter 7.1
and Page 49,
Chapter 13.1.
1) Window operation deactivated for values > 5094.
2) Operation with lter setting "F00" is not permitted, as EMC faults may occur in this case.
Table 13: SICK-specic service data UM18-21112A21_
