IO-Link interface
32 © SICK AG • Subject to change without notice • 8014865/ZUJ3/2018-11-29
8 IO-Link interface
The ultrasonic sensors with switching outputs are IO-Link-capable in
accordance with the V1.1 specication.
You can download the specic sensor IO-Link device description online
from "www.sick.com/um18".
NOTE!
If an ultrasonic sensor in SIO mode has been taught-in
via teach-in or via a "Connect+ Adapter," we recommend
resetting the sensor to its factory setting before
conguration using IO-Link.
8.1 Physical layer
Description Value
SIO mode
(standard I/O mode)
Yes
Output rate • UM18-217xxxxxx: 8 ms
• UM18-211xxxxxx: 8 ms
• UM18-212xxxxxx: 16 ms
• UM18-218xxxxxx: 20 ms
Speed COM2 (38.4 kBaud)
Process data width 16 bits (frame type 2.2)
Table 8: Physical layer
