SICK UM18-2 Pro User Manual

Identication
12 © SICK AG • Subject to change without notice • 8014865/ZUJ3/2018-11-29
3.2 Type code
U M 1 8 – 2 1 7 1 2 A 2 1 1
1 2 3 4 5 6 7 8 9 10 11 12 13
Position Description
1 to 4
Product family
UM18
5
Generation
2 2. Generation
6
Principle of operation
1 Scanning principle
7
Detection range
7 20 mm … 150 mm, 250 mm
1 30 mm … 250 mm, 350 mm
2 65 mm … 350 mm, 600 mm
8 120 mm … 1000 mm, 1300 mm
8 … 9
Connectionandhousingversion
12 M12 plug, 5-pin, nickel-plated brass without display
10
Output function
A 1x Push-pull switching output
B 2x Push-pull switching output
6 1x Analog output 4 mA ... 20 mA
7 1x Analog output DC 0 V … 10 V
11
IO-Link
2 available
1 not available
12
Performance
1 Pro version
13
Alignment
1 Straight
2 Angled
Table 1: Type code, UM18-2 Pro ultrasonic sensors
