Page #44 background imageLoading...
Page #44 background image
Technical data
44 © SICK AG • Subject to change without notice • 8014865/ZUJ3/2018-11-29
Hysteresis UM18-217xxxxxx: 2 mm
UM18-211xxxxxx: 3 mm
UM18-212xxxxxx: 5 mm
UM18-218xxxxxx: 20 mm
Congurable via "Connect+ Adapter"
Circuit protection Short-circuit protected
Maximum output current < 100 mA
Table 22: Outputs – sensors with switching outputs
11.5.2 Sensorswithanalogoutputs
Sensors with analog outputs UM18-2xxxx6xxx: 4 mA … 20 mA
UM18-2xxxx7xxx: DC 0 … 10 V DC
Analog output
UM18-2xxxx6xxx
4 mA … 20 mA
RL ≤ 500 Ω, at V
s
≤ 20 V: max. load ≤ 100 Ω
Rising, falling characteristic curve, congurable
Analog output
UM18-2xxxx7xxx
DC 0 … 10 V DC
RL ≥ 100 Ω
Rising, falling characteristic curve, congurable
Resolution 12 Bit
Circuit protection UM18-2xxxxx6xx: Voltage output is short-circuit protected
Table 23: Outputs – sensors with analog outputs
11.6 Interfaces
IO-Link For sensors with switching outputs
Connect+ Conguration interface for communication via "Connect+ Adapter"
accessories
Table 24: Interfaces
