3.5 Nominal operating conditions
The VMS4200/5200 multi-dimensional measurement system can determine the length,
width, and height of the smallest rectangular box that fully encloses cubic and irregularly
shaped measuring objects. The VMS5200 is certified to the Measuring Instruments
Directive specified in section 9.3 Compliance with EU directives.
The different nominal operating conditions according to the different nominal operating
conditions depending on the object size are described below.
3.5.1 Fixed scale values
If the plant is operated without scale value switchover, the measuring range and the scale
interval value are fixed throughout the entire system depending on the application, and
are therefore the same for all measured objects.
Measuring range and scale interval value for VMS5200 - operating condition 1
Min.
Max.
Scale value (d)
Note
Length
≥ 50 mm
≥ 2.0"
≤ 5,500 mm
≤
216.0"
5 mm
0.2"
Longest dimension of the measuring
object
Width
≥ 50 mm
≥ 2.0"
≤ 1,600 mm
≤
63.0"
5 mm
0.2"
Dimension of the measuring object
orthogonal to the longest dimension
Height
≥ 20 mm
≥ 1.0"
≤ 1,100 mm
≤ 43.0"
2 mm
0.1"
Maximum height of the measuring
object relative to the transport belt
surface
Tab. 1: Measuring range and scale interval value for VMS5200 - operating condition 1
Measuring range and scale interval value for VMS5200 - operating condition 2
Min.
Max.
Scale value (d)
Note
Length
≥ 50 mm
≥ 2.0"
≤ 5,500 mm
≤
216.0"
5 mm
0.2"
Longest dimension of the measuring
object
Width
≥ 50 mm
≥ 2.0"
≤ 1,600 mm
≤
63.0"
5 mm
0.2"
Dimension of the measuring object
orthogonal to the longest dimension
Height
≥ 50 mm
≥ 2.0"
≤ 1,100 mm
≤ 43.0"
5 mm
0.2"
Maximum height of the measuring
object relative to the transport belt
surface
Tab. 2: Measuring range and scale interval value for VMS5200 - operating condition 2
Measuring range and scale interval value for VMS5200 - operating condition 3
Min.
Max.
Scale value (d)
Note
Length
≥ 100 mm
≥ 4.0"
≤ 5,500 mm
≤
216.0"
10 mm
0.4"
Longest dimension of the measuring
object
Width
≥ 50 mm
≥ 2.0"
≤ 1,600 mm
≤
63.0"
5 mm
0.2"
Dimension of the measuring object
orthogonal to the longest dimension
Height
≥ 50 mm
≥ 2.0"
≤ 1,100 mm
≤ 43.0"
5 mm
0.2"
Maximum height of the measuring
object relative to the transport belt
surface
Tab. 3: Measuring range and scale interval value for VMS5200 - operating condition 3
