CAN
No. Connection for the LMS4x21
(slave)
Connection for the LMS4x21 (master)
4 POWER CAN IN POWER CAN OUT
4a POWER CAN OUT - termination
Synchronization
No. Connection for the
LMS4x21
Wire color SIM2000-2 Prime
terminal
Connection
5 Sync
Blue X4 INPUT A
4 IN2+
Gray X4 INPUT A
12 GND
ISO (X4)
Ethernet
No.
Connection for the LMS4x21
Port on LFT Ethernet switch
6
Ethernet
2
Tab. 12: Connection for LMS4x21 slave
LMS slave
