SICK WTB4S - Page 254

12.1 (0.48)
M8x1
7.6 (0.3)
8.9 (0.35)
18.6 (0.73)
11.3 (0.44)
3.7
(0
.
1
5)
18.6 (0.73)
25.4 (1)
12 (0.47)
30.5 (1.2)
5
4
3
2
1
4 4
插图 16: WTx4ST，DoubleLine，M8 插头
1
接收器光轴中心
2
发射器光轴中心
3
接口
4
紧固螺纹 M3
5
显示与设置元件
11.3 光点图
0
Distance in mm (inch)
Dimensions in mm (inch)
4
(0.16)
6
(0.24)
–6
(–0.24)
–4
(–0.16)
0
2
(0.08)
–2
(–0.08)
Recommended sensing range for
the best performance
150
(5.91)
100
(3.94)
50
(1.97)
200
(7.87)
250
(9.84)
300
(11.81)
10
(0.39)
250
(9.84)
110
(4.33)
插图 17: WTB4SP-xxxxx1xx
操作指南
254
操 作 指 南 | WTB4S 8028211/2023/10/20 | SICK
如有更改，恕不另行通知
zh
