Siegenia GENIUS 2.2 - Size Variants and Dimensions


GENIUS 2.2, Electromechanical mul-point lock
02.202010/44 H39.ELEKS013EN-00
 
K
I
F
F + 1 mm
B
G
A
C
Size
-

A B C F G I K



B296*
2170 760 355 380 1020
665 130
1505 - 1754
B298 2170 760 605 380 1020
415 130
1755 - 1880
B001 2170 760 730 380 1020
290 130
1881 - 2170
B003 2400 760 980 380 1020
270 130
2171 - 2400
B039*
1500 760 355 380 952 1505 - 1754
B041 1700 760 605 380 952 1755 - 1880
B166 1855 760 730 380 952 1881 - 2170
B253 2170 760 980 380 952 2171 - 2400
K038 1629 760 605 380 892 1755 - 1880
K002 1754 760 730 380 892 1881 - 2170
K054 2004 760 980 380 892 2171 - 2400

K010 2400 727 721 374 1050 500 190 1900 - 2400

B001 2170 756 734 377 1016
290 130
1881 - 2170

B001 2170 760 730 380 1020
290 130
1881 - 2170
B002 2170 760 730 380 1050
260 160
1911 - 2170
B166 1855 760 730 380 952 1881 - 2170
K007 1847 822.5 730 380 970 1881 - 2400
* = Not available with hole group "T0"
Dimensions
I + K
= can be shortened
F
= Middle of GENIUS to middle of lever
handle square spindle;
middle of magnec sensor = F + 1 mm
