Siegenia GENIUS 2.2 - GENIUS 2.2 (EB;CB) Connections

15/44

GENIUS 2.2, Electromechanical mul-point lock
15/4402.2020H39.ELEKS013EN-00
 

1
2
3
4
5
± 3 mm
Item 
[1] 
terminal A/B: data interface SI-BUS
Terminal C: supply voltage (- ) GND
Terminal D: supply voltage + 24 V DC
[2] 
Terminal 0/1: mode of operaon switch day/night mode
Terminal 2: supply voltage + 24 V DC
Terminal 3: supply voltage (-)
Terminal 4: input for external unlocking signal
at + 24 V DC ≥ 1 seconds = opening process
Terminal 7: feedback function for the locking status indicator
(adjustable via menu)
[3]
Buon with menu LED for menu navigaon to make all
adjustments of the GENIUS 2.2 B.
[4]
Status LED to indicate the current operang status; magnec
sensor
[5]

the magnet must be posioned centrally in relaon to the
magnec sensor [4] (permissible vercal tolerance ± 3 mm)
