Siegenia GENIUS 2.2 - Sash Side Assembly; Latch DIN Orientation


GENIUS 2.2, Electromechanical mul-point lock
02.202020/44 H39.ELEKS013EN-00
 
 
PZ 2
f
Insert a PZ2 screwdriver through
the hole at the rear of the gear
box.
f
Loosen the locking screws of
the latch sha with the PZ2
screwdriver unl the latch can
be pulled forwards and rotated
by 180°.
f
Rotate the latch by 180°.
f
Press in the latch and turn the
locking screw of the latch sha,
ghtening manually, using the
PZ2 screwdriver.
5x
f
Press the latch approx. 5 mes
into the gear box for the func-
on test.
f
The latch must be able to extend
again with ease.
