Siegenia GENIUS 2.2 - Cable and Wiring Diagrams


GENIUS 2.2, Electromechanical mul-point lock
02.202016/44 H39.ELEKS013EN-00
 
WARNING
-

You could suer an electric shock if you touch the
electrical components. Flying sparks could cause a
re. You could suer life-threatening injuries caused
by electric shock or re.
• Switch o unit prior to work.
• Pull the mains plug out of the socket.
• With a xed connecon at the 230-V AC mains
power supply, switch o the safety device at the
mains connecon.
 


5
4
3
2
1
5
4
3
2
1
5
4
3
2
1
Item 
1 
2 Mul-point lock AS 2x00
3 Access control system with SI-BUS
4 Cable transfer
5
Frame-integrated or rail nut power
supply,
voltage via SI-BUS
Item 
1 
2 Mul-point lock AS 2x00
3
Access control system (analogue)
e. g. ACS from third party producer
4 Cable transfer
5
Frame-integrated or rail nut power
supply,
voltage via analogue connecon
Item 
1 
2 Mul-point lock AS 2x00
3 Access control system with SI-BUS
4 Cable transfer
5
Frame-integrated or rail nut power
supply,
voltage via analogue connecon
