Siegenia GENIUS 2.2 - Screwing the Multi-Point Lock


GENIUS 2.2, Electromechanical mul-point lock
02.202026/44 H39.ELEKS013EN-00
 
1
f
Insert the mul-point lock in
the milled door leaf.
f
Adjust the mul-point lock to
the handle spindle [1]:
1
Ensure when you insert the GENIUS
into the routed pocket that the cable
is neither damaged nor kinked:
f
screw the mul-point lock to
the door leaf:
10 x
