GENIUS 2.2, Electromechanical mul-point lock
25/4402.2020H39.ELEKS013EN-00

+
1
0
-
4
7
1
2
+
-
1
0
4
7
f
Establish a plug connecon with
the KFV cable [1] and the green
PTR plug [2].
f
Tighten the screws of the PTR
plug by hand so that the wires
of the cable will not be able to
loosen themselves.
Check the rm seang.
+
-
1
0
4
7
1
+
-
1
0
4
7
f
Insert the green PTR plug [1]
into the connecon with the
designaon 0 to 7 of the GENIUS
2.2 B.
f
Route the cable and connect it
to a power supply and oponally
to an analogue access control
system (see chapter 4.3).
