Siegenia GENIUS 2.2 - Airgap Adjustment


GENIUS 2.2, Electromechanical mul-point lock
02.202032/44 H39.ELEKS013EN-00
 
Observe the assembly and operang instrucons for the door
hinges.
1
f
In accordance with the enclosed assembly instruc-
ons of the door hinge manufacturer, adjust the
airgap [1] between the faceplate and frame part.
An airgap of 3.5 mm ± 1.5 mm must be adhered to in order to
permit the KFV mul-point locks to funcon properly.
