GENIUS 2.2, Electromechanical mul-point lock
17/4402.2020H39.ELEKS013EN-00
 
A
SI-Bus
Siemensstr. 10 D-42551 Velbert
GEN 2.2 A
SN: R1: R2: R3:
24V DC
24V DC
Input n. c.
B C D 0 1 2 3
4
7
n. c.
n. c.
SI-BUS system
1
> = 1s
> = 1s
+V
L
N
PE
-V
A
SI-Bus
Siemensstr. 10 D-42551 Velbert
GEN 2.2 A
SN: R1: R2: R3:
24V DC
24V DC
Input n. c.
B C D 0 1 2 3 4 7
n. c.
n. c.
Power
supply
1
2
3
Item 
1 SI-BUS adapter cable
Item 
1 Unlocking via analogue access control system (oponal)
2 Feed (shielded)
3 Oponal external unlocking (e.g. buon or intercom system etc.)
