24 • Chapter 4 - Installation Guidelines ARTDriveG Instruction manual
Figure 4.1.2: AGy Mounting Methods for Sizes 1007...3150 (230V...480V) and 2002... 3020 (575V)
Mounting wall (D)Mounting with external dissipator (E)
E2 E4
E5
E3
E1
d
Table 4.1.2: AGy Mounting Methods for Sizes 1007...3150 (230V...480V) and 2002... 3020 (575V)
E1 E2 E3 E4 E5 Ød
1007
1015
1022
1030
2040
2055
2075
3110
3150
2002
2003
2005
3007
3010
3015
3020
agy3101
284 (11.2)
299.5 (11.8)164 (6.5) 315 (12.4)
145.5 (5.7)
199 (7.8)
9 (0.35)
AGy…-4 (230V…480V)AGy…-5 (575V)
M5
99.5 (3.9)
145.5 (5.7)
199 (7.8)
284 (11.2)
115 (4.5) 299.5 (11.7)
299.5 (11.8)
Type
9 (0.35)
Drive dimensions: mm (inch)
69 (2.7)
115 (4.5)
299.5 (11.7)
164 (6.5) 315 (12.4)
