Siei ARTDriveG - EMI Filter Connections for Sizes 4220

ARTDriveG Instruction manual Chapter 5 - Wiring Procedure • 53
5.7.3.2 EMI filter connections for Sizes 4220...71320 (230V...480V)
Supply
Cabinet Mounting panelInverter
Line
reactor
EMI-FN
filter
Ground
Bus
Motor cable
terminals
Motor
U, V, W
PE
U2, V2, W2
PE
Output
reactor
