96 • Chapter 7 - Parameters Description ARTDriveG Instruction manual
d.212 An in 2 term mon (Analog input 2 terminals monitor)
Analog input 2 - block input (%). See Fig. 7.4.1.
It monitors the signal at the An In 2 regulation board terminals, according to the value of An inp 2 Type (I.210)
parameter:
• selection: [0] +/- 10V: 0V = 0%, -10V = -100%, +10V = +100%
• selection: [1] 0-10V/0-20mA:0V = 0%, +10V = +100%
d.220 An in 3 cnf mon (Analog input 3 configuration monitor)
Monitor of the function associated to Analog input 3. See param. d.200.
d.221 An in 3 monitor (Analog input 3 monitor)
Analog input 3 - block output (%). See Fig. 7.4.1.
d.222 An in 3 term mon (Analog input 3 terminals monitor)
Analog input 3 - block input (%). See Fig. 7.4.1.
It monitors the signal at the An In 3 regulation board terminals, according to the value of An inp 3 Type (I.220)
parameter:
• selection: [1] 0-10V/0-20mA:0mA = 0%, 20mA = +100%
• selection: [2] 4-20mA: 4mA = 0%, 20mA = +100%
Code LCD display [Code] & LCD select. Default MIN MAX Unit Variation IPA
d.100 Dig inp status 014
d.101 Term inp status 015
d.102 Vir dig inp stat 016
d.120 Exp dig inp stat 017
d.121 Exp term inp 018
d.122 Vir exp dig inp 019
d.150 Dig out status 020
d.151 Drv dig out sta 021
d.152 Vir dig out stat 022
d.170 Exp dig out stat 023
d.171 Exp DrvDigOutSta 024
d.172 Exp VirDigOutSta 025
d.200 An in 1 cnf mon 026
d.201 An in 1 monitor % 027
d.202 An in 1 term mon % 028
d.210 An in 2 cnf mon 029
d.211 An in 2 monitor % 030
d.212 An in 2 term mon % 031
d.220 An in 3 cnf mon 032
d.221 An in 3 monitor % 033
d.222 An in 3 term mon % 034
Encoder
d.300 EncPulses/Sample (Encoder Pulses / Sample)
Number of encoder pulses, recorded in the time interval defined by parameter I.504.
d.301 Encoder freq (Encoder frequency)
Frequency detected by the encoder (Motor electrical frequency) [Hz]
