Siei ARTDriveG - External Braking Resistor

56 • Chapter 5 - Wiring Procedure ARTDriveG Instruction manual
5.8.1.1 External Braking Resistor
Recommended resistors for use with internal braking unit:
Table 5.8.1.3: Lists and Technical Data of the External Standard Resistors
Drive
P
NBR
R
BR
E
BR
Resistor
Type [kW] [Ohm] [kJ] Type a b c a1 b1
1007 … 2040
0.6 100 22
MRI/T600 100R
S8SS3 1.5 (3.3) 320 (12.6) 120 (4.7) 100 (3.9) 360 (14.2)
2055 … 2075
0.9 68 33
MRI/T900 68R
S8SS2 2.7 (6.0) 320 (12.6) 160 (6.3) 120 (4.7) 380 (15.0)
3110
1.3 49 48
MRI/T1300 49R
S8ST4 3.7 (8.2) 320 (12.6) 320 (12.6) 120 (4.7) 380 (15.0)
3150
2.1 28 90
BR T2K0-28R
S8T00F 498 (19.6) 100 (3.9) 250 (9.8) 478 (18.8) 40 (1.6)
4220
4 15.4 180
BR T4K0-15R4
S8T00G 7.0 (15.4) 625 (24.6) 100 (3.9) 250 (9.8) 605 (23.8) 40 (1.6)
4300…4370
4 11.6 180
BR T4K0-11R6
S8T00H 7.0 (15.4) 625 (24.6) 100 (3.9) 250 (9.8) 605 (23.8) 40 (1.6)
5450…5550
8 7.7 360
BR T8K0-7R7
S8T00I 11.5 (25.) 625 (24.6) 160 (6.3) 250 (9.8) 605 (23.8) 60 (2.4)
2002…2005
0.6 140
22
MRI/T600 140R
S8SY7 1.5 (3.3) 320 (12.6) 120 (4.7) 100 (3.9) 360 (14.2)
3007…3010
0.9 100 33
MRI/T900 100R
S8SY8 2.7 (6.0) 320 (12.6) 160 (6.3) 120 (4.7) 380 (15.0)
3015
1.3 74 48
MRI/T1300 74R
S8SY9 3.7 (8.2) 320 (12.6) 205 (8.7) 120 (4.7) 380 (15.0)
3020
2.1 42 90
BR T2K0-42R
S8T00M 498 (19.6) 100 (3.9) 250 (9.8) 478 (18.8) 40 (1.6)
4025…4030
4 23 180
BR T4K0-23R
S8T00N 7.0 (15.4) 625 (24.6) 100 (3.9) 250 (9.8) 605 (23.8) 40 (1.6)
4040…4050
4 18 180
BR T4K0-18R
S8T00O 7.0 (15.4) 625 (24.6) 100 (3.9) 250 (9.8) 605 (23.8) 40 (1.6)
5060…5075
8 11.6 180
BR T8K0-11R6
S8T00R 11.5 (25.) 625 (24.6) 160 (6.3) 250 (9.8) 605 (23.8) 60 (2.4)
agy0707
AGy…-5 (575V)
Weight
kg (lbs)
Dimensions : mm (inch)
SIEI code
AGy…-4 (230V…480V)
Figure 5.8.2: External resistors
a
b
C
a1
MRI/T600...,/T900...,/T1300…
BR T2K0..., BR T8K0
a
c
BR T2K0: PG 11/PG16
b
BR T4K0: PG 13
BR T8K0: PG 16
PG 7: on version with
Thermostat only
a
b1
c
13x6.5
b
a1
b1
=
=
PG 11 PG 7
* PG7 on version
with thermostat only
BR T12K0...
Parameters description:
P
NBR
Nominal power of the braking resistor
R
BR
Braking resistor value
E
BR
Max surge energy which can be dissipated by the resistor
P
PBR
Peak power applied to the braking resistor
T
BRL
Maximum braking time in condition of limit operating cycle (braking power = P
PBR
with typical
triangular profile)
T = 2 = [s]
BRL
E
BR
P
PBR
